Technical information
Article title
Subway 3.0 Single-lever bath & shower mixer, Chrome
Article number
TVT11200200061
Assembly / Assembly type
wall-mounted
Scope of delivery
1 x tap fitting
1 x aerator key
1 x fastening
1 x installation instructions
1 x S-connection
Length in mm
232
Width in mm
303
Height in mm
108
Collection
Subway 3.0
Weight in kg
2,94
Material
Brass
Colour name
Chrome
EAN number
4062373800638
Model number
TVT112002000
Air plus
An aerator enriches the water with air for a particularly soft, water-saving jet
Easy clean
Longer service life: optimum limescale removal by simply rubbing nozzles and aerators clean
Tap smartpressure
Constant water flow rate for washbasin mixers regardless of pressure fluctuations in the piping system
Length of spout in mm
209
General information
With adjustable aerator
Spacing of connection spigots in mm
150
Material
Brass
Angle jet regulator
10
Cartridge
Cartridge with ceramic discs
Connection dimensions
150
Handle position
Links
Diameter of faucet body
43
Thermostat
No
Cool Tap
No
