Washdown toilet for close-coupled WC-suite, rimless

Architectura

SPECIFICATION TEXTS

5691R001

discontinued

Architectura DirectFlush Washdown toilet for close-coupled WC-suite, rimless, floor-standing, with DirectFlush, White Alpin

SIZE AND SHAPE :
Width in mm
370
Length in mm
700
Height in mm
400
Form
Oval
COLOUR AND SURFACE :
Colour designation
White Alpin
PROPERTIES :
Assembly / Assembly type
floor-standing back to wall
Assembly instructions
recommendation: to be installed from the wall at: 15 mm
Suitable for
Mounted cistern
Rimless
Yes
Innovative flushing technology (with TwistFlush)
No
Innovative flushing technology (with TwistFlush[e³])
No
Flush type
Washdown toilet
Flush volume l
3 - 4.5 l
Outlet / outlet
horizontal outlet
Wall-mounted - floor-standing
floor-standing
Leed
4
Material
Sanitary ceramics
Colour name
White Alpin
Article number:

5691R001

Material status:

Discontinued item

    Technical information
    back

    Technical information

    Article title

    Architectura DirectFlush Washdown toilet for close-coupled WC-suite, rimless, floor-standing, with DirectFlush, White Alpin

    Article number

    5691R001

    Assembly / Assembly type

    floor-standing

    back to wall

    Assembly instructions

    recommendation: to be installed from the wall at: 15 mm

    Scope of delivery

    1 x washdown toilet, rimless

    1 x fastening set

    Ordering information

    Please order cistern separately.

    Length in mm

    700

    Width in mm

    370

    Height in mm

    400

    Collection

    Architectura

    Weight in kg

    37,30

    Suitable for

    Mounted cistern

    Rimless

    Yes

    Innovative flushing technology (with TwistFlush)

    No

    Innovative flushing technology (with TwistFlush[e³])

    No

    Flush type

    Washdown toilet

    Flush volume l

    3 - 4.5 l

    Outlet / outlet

    horizontal outlet

    Wall-mounted - floor-standing

    floor-standing

    Leed

    4

    Material

    Sanitary ceramics

    Colour name

    White Alpin

    EAN number

    4051202473396

    Model number

    5691R0

    accessories
    back

    accessories

    Villeroy & Boch Architectura Cistern, water inlet from the sides or rear, White Alpin
    Collection Architectura
    Product designation Cistern
    Article number 5787G101
    Dimension 387 x 165 x 385 mm
    to product detail
    Suitable products
    back

    Suitable products

    Villeroy & Boch Architectura previously Omnia Architectura Toilet seat and cover SlimSeat, with automatic lowering mechanism (SoftClosing), with removable seat (QuickRelease), White Alpin
    Collection Architectura
    Product designation Toilet seat and cover SlimSeat
    Article number 9M70S101
    Dimension 374 x 439 x 48 mm
    to product detail
    Villeroy & Boch Architectura previously Omnia Architectura Toilet seat and cover SlimSeat, White Alpin
    Collection Architectura
    Product designation Toilet seat and cover SlimSeat
    Article number 9M706101
    Dimension 374 x 439 x 48 mm
    to product detail
    Villeroy & Boch Architectura previously Omnia Architectura Toilet seat and cover, with automatic lowering mechanism (SoftClosing), with removable seat (QuickRelease), White Alpin
    Collection Architectura
    Product designation Toilet seat and cover
    Article number 98M9C101
    Dimension 374 x 445 x 59 mm
    to product detail
    Villeroy & Boch Architectura previously Omnia Architectura Toilet seat and cover, White Alpin
    Collection Architectura
    Product designation Toilet seat and cover
    Article number 98M9D101
    Dimension 376 x 452 x 42 mm
    to product detail
    Show more
    Spareparts
    back

    Spareparts

    Villeroy & Boch Spare parts Fastening set, 133x183mm, White Alpin
    Product designation Fastening set
    Article number 92248701
    to product detail
    downloads
    back

    Installation & assembly

    Assembly instructions

    VB-Architectura-5691R0-II-v02-43635-en.pdf
    Assembly instructions

    VB-Architectura-5691R0-II-v03-43636-en.pdf
    Technical drawing

    VB-Architectura-5691R0-2D01-v00-39446.pdf
    Technical drawing

    VB-Architectura-5691R0-2D01-v00-39447.pdf

    Planning information

    2-D data

    VB-Architectura-5691R0-2D01-v00-39446.dwg
    2-D data

    VB-Architectura-5691R0-2D01-v00-39446.dxf
    2-D data

    VB-Architectura-5691R0-2D01-v00-39446.eps
    2-D data

    VB-Architectura-5691R0-2D01-v00-39447.dwg
    2-D data

    VB-Architectura-5691R0-2D01-v00-39447.dxf
    2-D data

    VB-Architectura-5691R0-2D01-v00-39447.eps
    3-D data

    VB-Architectura-5691R0-3D01-v00-42813.stp
    BIM data

    Item documentation

    Exploded-view drawing

    VB-Architectura-5691R0-EXPL-v00-50095.pdf
    Declaration of Performance (DOP)

    VB-S-YTD-C413-0001-v04-57462.pdf
