Collaro Washbasin, 550x440x160mm, with overflow, White Alpin

Collaro Washbasin, 550x440x160mm, with overflow, White Alpin Collaro Washbasin, 550x440x160mm, with overflow, White Alpin Collaro Washbasin, 550x440x160mm, with overflow, White Alpin Collaro Washbasin, 550x440x160mm, with overflow, White Alpin Collaro Washbasin, 550x440x160mm, with overflow, White Alpin Collaro Washbasin, 550x440x160mm, with overflow, White Alpin Collaro Washbasin, 550x440x160mm, with overflow, White Alpin Collaro Washbasin, 550x440x160mm, with overflow, White Alpin Collaro Washbasin, 550x440x160mm, with overflow, White Alpin
Collaro Washbasin, 550x440x160mm, with overflow, White Alpin
Collaro Washbasin, 550x440x160mm, with overflow, White Alpin
Collaro Washbasin, 550x440x160mm, with overflow, White Alpin
Collaro Washbasin, 550x440x160mm, with overflow, White Alpin
Collaro Washbasin, 550x440x160mm, with overflow, White Alpin
Collaro Washbasin, 550x440x160mm, with overflow, White Alpin
Collaro Washbasin, 550x440x160mm, with overflow, White Alpin
Collaro Washbasin, 550x440x160mm, with overflow, White Alpin
Collaro Washbasin, 550x440x160mm, with overflow, White Alpin
View

Washbasin

Collaro

SPECIFICATION TEXTS Technical data sheet All downloads

SPECIFICATION TEXTS

4A335501

Collaro Washbasin, 550x440x160mm, with overflow, White Alpin

SIZE AND SHAPE :
Width in mm
550
Length in mm
440
Height in mm
160
Form
Rectangle
COLOUR AND SURFACE :
Colour designation
White Alpin
PROPERTIES :
Assembly / Assembly type
wall-mounted
Interior depth
85
Number of tap holes punched through
1
Number of tap holes pre-drilled
2
Position of drill hole
central tap hole punched out
Suitable for
3-hole mixer Matching Villeroy&Boch furniture
Material
TitanCeram
Colour name
White Alpin
With TitanGlaze
No
With overflow
Yes
Article number:

4A335501

availability:
    Collaro

    Washbasin

    Technical information
    back

    Technical information

    Article title

    Collaro Washbasin, 550x440x160mm, with overflow, White Alpin

    Article number

    4A335501

    Assembly / Assembly type

    wall-mounted

    Scope of delivery

    1 x washbasin

    Ordering information

    Optionally available: Outlet valve with ceramic cover.

    Length in mm

    440

    Width in mm

    550

    Height in mm

    160

    Interior depth

    85

    Collection

    Collaro

    Weight in kg

    16,40

    Number of tap holes punched through

    1

    Number of tap holes pre-drilled

    2

    Position of drill hole

    central tap hole punched out

    Suitable for

    3-hole mixer

    Matching Villeroy&Boch furniture

    Material

    TitanCeram

    Colour name

    White Alpin

    With TitanGlaze

    No

    With overflow

    Yes

    EAN number

    4051202864460

    Model number

    4A3355

    accessories
    back

    accessories

    Villeroy & Boch ViConnect installation systems Washbasin installation element, for Dry-wall construction, 525x75x1120mm
    Collection ViConnect installation systems
    Product designation Washbasin installation element
    Article number 92214900
    Dimension 525 x 1120 x 135 mm
    to product detail
    Villeroy & Boch Accessories Cap (overflow cover), 42x43x32mm, Star White
    Collection Accessories
    Product designation Cap (overflow cover)
    Article number 79010096
    Dimension 42 x 43 x 32 mm
    to product detail
    Villeroy & Boch Accessories Easy Access siphon, 205x350x62.5mm
    Collection Accessories
    Product designation Easy Access siphon
    Article number 92198800
    Dimension 205 x 350 x 62,5 mm
    to product detail
    Suitable products
    back

    Suitable products

    Villeroy & Boch Collaro Vanity unit, 2 pull-out compartments, 510x546x414mm, Body: Taupe, Front: Taupe
    Collection Collaro
    Product designation Vanity unit
    Article number C00700VM
    Dimension 510 x 546 x 414 mm
    to product detail
    Villeroy & Boch Collaro Vanity unit, with lighting, 2 pull-out compartments, 510x546x414mm, Body: Glossy White, Front: Glossy White
    Collection Collaro
    Product designation Vanity unit
    Article number C007B0DH
    Dimension 510 x 546 x 414 mm
    to product detail
    downloads
    back

    Installation & assembly

    Technical drawing

    VB-Collaro-4A3355-2D01-v00-39141.pdf

    Planning information

    2-D data

    VB-Collaro-4A3355-2D01-v00-39141.dwg
    2-D data

    VB-Collaro-4A3355-2D01-v00-39141.dxf
    2-D data

    VB-Collaro-4A3355-2D01-v00-39141.eps
    3-D data

    VB-Collaro-4A3355-3D01-v00-42617.stp
    BIM data

    Item documentation

    Declaration of Performance (DOP)

    VB-S-YTD-A113-0001-v15-57457.pdf
