Subway Infinity Rectangular shower tray, 1200x800x40mm, White Alpin

View

Rectangular shower tray

SPECIFICATION TEXTS Technical data sheet All downloads

SPECIFICATION TEXTS

6231Q301

Article title:  Subway Infinity Rectangular shower tray, 1200x800x40mm, White Alpin
Article number: 6231Q301
Assembly / Assembly type: flush-fitting installation
Assembly instructions: Ceramic available in White Alpin (01) with anti-slip class B (PN18).

These shower trays are cut along four sides (unglazed) and can only be used for flush installation.

The installation height of the shower can be reduced by 30mm if outlet fitting 9226 00 XX is used. <br>Please note: this outlet fitting does not conform to EN 274.

Total price includes the surcharge for cutting!

*Shower trays marked with an asterisk can only be installed with ViFrame installation system or in a mortar bed.

Orders that we have confirmed for custom-made shower trays cannot be cancelled or altered.

Shower tray, stepless access
Scope of delivery: 1 x rectangular shower tray
Ordering information: Orders that we have confirmed for custom-made shower trays cannot be cancelled or altered.
Length in mm: 1200
Width in mm: 800
Height in mm: 40
Interior depth: 12
Collection: Subway Infinity
Weight in kg: 39.4
Material: Sanitary ceramics
Colour name : White Alpin
With feet/base: No
With bath support: No
Anti-slip class: Anti-slip class B
EAN number: 4051202469801
Model number: 6231Q3

SIZE AND SHAPE :

Width in mm

800

Length in mm

1200

Height in mm

Form

Rectangle

COLOUR AND SURFACE :

Colour designation

White Alpin

PROPERTIES :

Assembly / Assembly type

flush-fitting installation

Assembly instructions

Ceramic available in White Alpin (01) with anti-slip class B (PN18). These shower trays are cut along four sides (unglazed) and can only be used for flush installation. The installation height of the shower can be reduced by 30mm if outlet fitting 9226 00 XX is used. <br>Please note: this outlet fitting does not conform to EN 274. Total price includes the surcharge for cutting! *Shower trays marked with an asterisk can only be installed with ViFrame installation system or in a mortar bed. Orders that we have confirmed for custom-made shower trays cannot be cancelled or altered. Shower tray, stepless access

Interior depth

Material

Sanitary ceramics

Colour name

White Alpin

With feet/base

With bath support

Anti-slip class

Anti-slip class B

Article number:

6231Q301

availability:

Subway Infinity

Rectangular shower tray

Technical information

back

Technical information

Article title

Subway Infinity Rectangular shower tray, 1200x800x40mm, White Alpin

Article number

6231Q301

Assembly / Assembly type

flush-fitting installation

Assembly instructions

Ceramic available in White Alpin (01) with anti-slip class B (PN18).

These shower trays are cut along four sides (unglazed) and can only be used for flush installation.

The installation height of the shower can be reduced by 30mm if outlet fitting 9226 00 XX is used.
Please note: this outlet fitting does not conform to EN 274.

Total price includes the surcharge for cutting!

*Shower trays marked with an asterisk can only be installed with ViFrame installation system or in a mortar bed.

Orders that we have confirmed for custom-made shower trays cannot be cancelled or altered.

Shower tray, stepless access

Scope of delivery

1 x rectangular shower tray

Ordering information

Orders that we have confirmed for custom-made shower trays cannot be cancelled or altered.

Length in mm

1200

Width in mm

800

Height in mm

Interior depth

Collection

Subway Infinity

Weight in kg

39,40

Material

Sanitary ceramics

Colour name

White Alpin

With feet/base

With bath support

Anti-slip class

Anti-slip class B

EAN number

4051202469801

Model number

6231Q3

accessories

back

accessories


Collection	Subway Infinity
Product designation	Tempoplex Plus outlet Compact Ø 90mm
Article number	92260061
Dimension	380 x 140 x 120 mm

to product detail


Collection	Subway Infinity
Product designation	Tempoplex Plus outlet Ø 90mm
Article number	92250068
Dimension	380 x 140 x 120 mm

to product detail


Collection	Accessories
Product designation	ViFrame installation frame, for smaller shower trays (up to 1000 x 1000 mm) made of ceramic or acrylic, height adjustable 90-175 mm, incl. 2 central feet
Article number	U91412100
Dimension	400 x 820 x 100 mm

to product detail


Collection	Accessories
Product designation	ViFrame installation frame, for larger shower trays (from 1000 x 1000 mm) made of ceramic or acrylic, height adjustable 90-175 mm, incl. 4 central feet
Article number	U91412200
Dimension	320 x 1200 x 10 mm
