Technical information
Article title
ViConnect installation systems Pneumatic flushing, No, Dual flush, Chrome
Article number
92215061
Assembly instructions
Easy connection to flush plate via flexible cables with bayonet joint
Scope of delivery
1 x suspension frame and fastening bolt
Ordering information
Distance frame for covering uneven tile edges optionally available
Length in mm
249
Width in mm
181
Height in mm
68.5
Collection
ViConnect installation systems
Weight in kg
0,26
Suitable for
Dual flush
Material
Plastic
Colour name
Chrome
Activation / Flush
front-operated
Technical information
Outer diameter 80 mm, operating panel diameter 60 mm
water-saving dual flush plate
Height over tiles 4 mm, for furniture wall thicknesses of up to 20 mm, for minimum hole diameter of 69 mm in room wall, minimum installation depth from front edge of furniture to rear edge of pneumatic flush plate unit 80 mm
EAN number
4051202486945
Model number
922150
